Chauvet Pro COLORado Batten 72X IP65 Wash Light

The Chauvet Pro COLORado Batten 72X IP65 Wash Light is a class leading, powerful IP65 batten-style wash light powered by 72 calibrated RGBWA LEDs. The compact, tour-ready unit produces superb color rendering and a vast palette from soft pastels to saturated hues. Its 16-bit dimming capability, as well as five selectable dimming curves provides smooth fades and facilitate its incorporation into aging traditional rigs. Integrated trunnions accommodate clamps for vertical or horizontal hanging.



Product Specifications:

Optical:

Light Source: 72 LEDs (18 red, 18 green, 18 blue, 9 white, 9 amber) 3 W, (690 mA), 50,000 hours life expectancy

Color Temperature (range): 3200 to 10000 K

CRI (3200 K): 80

Installed Optics: 24°

Beam Angle (Horizontal): 22°

Beam Angle (Vertical): 18°

Field Angle (Horizontal): 39 °

Field Angle (Vertical): 34°

Lumens: 3,631

Illuminance (total): 1730 lux @ 5 m

Selectable PWM: 600, 1200 Hz, 2000, 2400 Hz, 4000 Hz, 6000 Hz, 25000 Hz

Dynamic Effects:

Dimmer: Electronic

Shutter/Strobe: Electronic

Strobe Rate: 0 to 25 Hz

Standalone Color Mixing: Yes

Color Temperature Presets: Yes

Dim Modes: 5

Built-in Automated Programs: Yes

Customizable Programs: Yes

Recall Custom Programs: Yes

Construction / Physical:

Dimensions: 39.37 x 6.14 x 2.95 in (1000 x 156 x 75 mm)

Weight: 18.6 lb (8.4 kg)

Exterior Color: Black

Housing Material: Aluminum alloy, Aluminum die-cast

Connections:

Power Connection: Edison (Local) plug to Seetronic Powerkon IP65

Power Input: Seetronic Powerkon IP65

Power Output: Seetronic Powerkon IP65

Data Connectors: 5-pin IP65 XLR

Cable Length (power): 5 ft (1.5 m)

Control:

Control Protocol: DMX, RDM

DMX Channels: 1 Cell: 3, 4, 5, 8, 8, 9, 10, 10, 16

3 Cell: 9, 12, 15, 21, 22, 24, 27, 30, 43

Modes/Personalities: 18 personalities

Electrical:

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

Power Linking: 10 units @ 120 V; 17 units @ 208 V; 19 units @ 230 V

Power and Current: 161 W, 1.33 A @ 120 V, 60 Hz

Power and Current: 164 W, 0.79 A @ 208 V, 60 Hz

Power and Current: 163 W, 0.71 A @ 230 V, 50 Hz

Certifications / Qualifications

CE, MET

IP Rating: IP65, temporary outdoor/wet use

Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included:

COLORado Batten 72X

Seetronic powerKON IP65 power cord

(2) Omega bracket

Optional Accessories:

Professional Clamps: CTC-50HC, CTC-50HCN

Neutrik TRUE1 power linking cables

5-pin IP DMX Cables
