Chauvet Pro Maverick Force X Profile, 520W LED Moving Head Profile Fixture with Framing Shutters

The Chauvet Professional Maverick Force X Profile is a compact, high-output LED moving profile fixture designed for touring, theatre, broadcast, and professional stage applications that demand versatility, precision, and reliability. Powered by a 520W cool white LED engine, it delivers an impressive 18,963 lumens of output with a clean, flat field and excellent beam consistency. Its lightweight yet robust construction makes it ideal for both short-throw and long-throw applications where performance and flexibility are critical.

Equipped with an expansive 3.5° to 57.3° zoom range, the fixture provides smooth beam transitions from tight aerial effects to wide stage coverage. Advanced CMY color mixing combined with a dedicated color wheel featuring CRI and CTB filters ensures accurate color reproduction and smooth blending. Dual gobo wheels-one rotating and one static-allow for layered projection effects, while the 5-facet prism, iris, and frost functions expand creative beam-shaping possibilities for dynamic visual design.

The Maverick Force X Profile also features a precise four-blade framing shutter system with dual-axis movement, full wipe capability, and 120° module rotation for accurate beam control. Smooth 16-bit dimming and high-speed 65,000 Hz PWM ensure flicker-free operation for camera use and seamless fades. With support for DMX, WDMX, sACN, Art-Net, and CRMX, along with RDM control, NFC setup, USB updates, battery-backed display, and failsafe Ethernet connectivity, it delivers advanced control and exceptional reliability for demanding professional environments.

Product Specifications:

Light Source: 1 × 520W Cool White LED (6966K)

LED Lifespan: 50,000 Hours

Color Temperature (Full): 6966K

CRI: 72.2 (91.9 with CRI Filter)

CQS: 70.2 (90 with CRI Filter)

TLCI: 51 (78 with CRI Filter)

CTO: 3200K / 4300K

CTB: 8200K

Lumens Output: 18,963 lm

Illuminance (3.4°): 104,429 lux @ 5m

Illuminance (57.3°): 1,219 lux @ 5m

Beam Angle: 3.4° to 52.2°

Field Angle: 3.7° to 55.3°

Cutoff Angle: 3.8° to 57.3°

Zoom Range: 3.5° to 57.3° (Motorized)

Front Lens Diameter: 145 mm

Dimmer: Electronic (5 Curves)

Strobe Rate: 0 to 25 Hz

Pan: 540° / 360° / 180° selectable

Tilt: 270° / 180° / 90° selectable

Color System: 7 Colors + White + CMY Wheels + CMY Macros

Gobos (Wheel 1): 7 + Open (Metal & Glass, Rotating, Indexing)

Gobos (Wheel 2): 9 + Open (Metal, Continuous Scroll)

Gobo Size: 23.9 mm outer / 14 mm image / 1.1 mm max thickness

Framing Shutters: Yes

Focus: Motorized

Zoom: Motorized

Iris: Motorized

Frost: Motorized

Prism: 5-Facet Motorized Rotating

Control Protocols: DMX, Art-Net, sACN, CRMX, NFC

DMX Channels: 31 / 47

Power Consumption: 576-595W (varies by voltage)

Input Voltage: 100-240V AC, 50/60Hz

Power Connector: Seetronic PowerCON IP65

Data Connectors: 3-pin & 5-pin XLR, etherCON IP65

Battery Type: Lithium-Ion (Display Backup)

Battery Life: 1 Hour

Battery Charge Time: 5 Hours

IP Rating: IP20 (Dry Location)

Noise Level (Max): 38.8 dB(A) @ 1m

Housing Material: Aluminium Alloy, Die-cast Aluminium, Steel, Flame-Retardant Polymer

Temperature Range: -20°C to 45°C (-4°F to 113°F)

Certifications: CE, MET, FCC, UKCA

Weight: 23.1 kg (50 lbs)

Dimensions: 361 × 239 × 646 mm (14.21 × 9.40 × 25.43 in)

Shipping Weight: 58.42 lbs.

Shipping Dimensions (L x W x H): 28.54 x 13.19 x 16.93 in
