Crown Audio CT875 8-Channel Power Amplifier - 75 Watt
Crown Audio CT875 8-Channel Power Amplifier - 75 Watt
Model / SKU: H-CROW-CT875
That combination of options is not offered. Choose different options, or call us and we will sort it out.
Added to your quote list. View quote list (0)
In a hurry? Call us.
- 1-800-700-4542
- System design direct line: (213) 816-4102
Free system design. Real people, Mon to Sat, 10 to 5 Pacific.
The Crown CT875 is an 8-channel power amplifier is designed to deliver professional audio performance in an ultra-slim form factor. Its compact 1RU chassis fits easily into standard equipment racks, making it ideal for space-restricted installations. Each channel provides 75W into 8 ohms with low distortion, ensuring clean, powerful, and consistent audio output. With Drive Core technology, the amplifier achieves over 90% efficiency, offering exceptional performance while maintaining a low power footprint.
A key advantage of the CT875 is its fan less, convection-cooled design, which ensures completely silent operation, perfect for environments where noise must be minimized. The amplifier also features flexible input routing, allowing any input signal to be assigned to any of the outputs, providing adaptability for various system configurations and installation requirements.
To ensure long-term reliability, the CT875 includes integrated life-safety features along with patented feedback and protection circuitry. These systems guard against potential damage from overloads or faults, extending the life of the amplifier. Additionally, the universal power supply supports global operation, making the CT875 suitable for international installations and touring applications where consistent performance and reliability are essential.
Product Specifications:
Channels: 8
Sensitivity: 1.4 V
Rated Power Output (all channels driven): 75W per CH @ 4 ohms, 75W per CH @ 8 ohms
Signal to Noise Ratio (below rated power 20 Hz to 20 kHz, A-Weighted): 110 dB
THD (full rated power, 20 Hz - 20 kHz): < 0.05%
Intermodulation Distortion (from 0 dB down to -30 dB): < 0.05%
Frequency Response (at 1W, 4/8 ohms): +/- 0.5 dB
Crosstalk (below rated power) 20 Hz to 1 kHz: > 70 dB
Common Mode Rejection (20 Hz to 1 kHz): > 55 dB, typically > 70 dB
Voltage Gain: 25 dB
DC Offset: +/- 20mV
Idle Power Consumption (Standard Mode): 23.0W
IEC Power Connector: 15A
Product Weight: 10 lbs.
Product Dimensions (L × W × H): 15.19" × 19" × 1.75"
Shipping Weight: 15 lbs.
