JBL AWC15LF-BK All-Weather Compact Low-Frequency Speaker w/ 15" LF
JBL AWC15LF-BK All-Weather Compact Low-Frequency Speaker w/ 15" LF
Model / SKU: H-JBL-AWC15LFBK
That combination of options is not offered. Choose different options, or call us and we will sort it out.
Added to your quote list. View quote list (0)
In a hurry? Call us.
- 1-800-700-4542
- System design direct line: (213) 816-4102
Free system design. Real people, Mon to Sat, 10 to 5 Pacific.
The JBL AWC15LF-BK is a compact highly weather resistant loudspeaker for augmenting the low frequency capability of a sound system. AWC15LF is ideal for many applications, including sports facilities, racetracks, stadiums, fairgrounds, rodeos, skating rinks, themed entertainment venues, cruise ships, water parks, outdoor background music systems, swimming pools, and a wide variety of other outdoor and indoor venue types.
Product Specifications:
Frequency Range (-10dB): 45 Hz, 2.2 kHz
Frequency Response (±3 dB): 70 Hz, 1.2 kHz
System Power Rating: 500 W (2000 W peak), 2 hrs. 300 W (1200 W peak), 100 hrs.
Sensitivity (2.83V @ 1m): 94 dB (Ave. 80 Hz, 300 Hz)
Maximum SPL (1m): Direct 8Ω: 121 dB (peaks of 127 dB) 300 W Tap: 119 dB (peaks of 125 dB)
Nominal Impedance: 8 ohms (in Direct mode)
Transformer Taps: 70V: 300W, 150W, 75W, 38W 100V: 300W, 150W, 75W
Enclosure: ABS with Glass enclosure, heavily braced
Dimensions: 486 x 486 x 479 mm (19.1 x 19.1 x 18.8)
Included Accessories: U-bracket, matches loudspeaker color (gray or black)
Nominal LF Driver Impedance: 8 ohms (in Direct mode)
Suspension Attachment: Two M10 (fine-thread) points for included U-bracket.
Net Weight (each): 20.2 kgs. (44.5 lbs.)
Coverage Pattern: Omnidirectional
