The Yamaha CZR15W (White) is a powerful 2-way loudspeaker engineered for professional live sound and fixed installations where high output and exceptional clarity are essential. Its compact yet rugged design makes it ideal for demanding applications-from live bands on outdoor stages to club installs, delivering articulate highs and deep, impactful low frequencies in a highly portable format.
Equipped with a 15" low-frequency driver and a 2" high-frequency compression driver, the CZR15W features Yamaha’s proprietary Wide Dispersion CD Waveguide horn for consistent coverage and balanced sound across the venue. With 800W (PGM) power handling and bi-amp capability, it provides strong headroom and dynamic performance. The floor monitoring setting also enables easy conversion for stage monitor use.
Built for reliability on the road, the CZR15W (White) features a lightweight yet highly durable plywood cabinet finished with premium-grade Polyurea coating. A dual-angle pole socket, rotatable horn, and optional U-bracket rigging options (UB-DZR15H/V) allow flexible placement and mounting. The professional white finish ensures a clean, discreet look in any live or installed sound environment.
Product Specifications:
Speaker Type: 2-way Speaker, Bass-reflex
Color: White
Frequency Range (-10 dB): Passive 43 Hz, 20 kHz; Normal 34 Hz, 20 kHz; FOH 33 Hz, 20 kHz
Coverage Area: H90° × V50° Rotatable Constant Directivity Horn
Floor Monitor Angle: 50° Symmetrical
LF Component: 15" Cone, 3" Voice Coil, Neodymium Magnet
HF Component: 2" Voice Coil, 1" Throat Compression Driver, Titanium Diaphragm, Neodymium Magnet
Crossover: 2.0 kHz
Power Rating (NOISE): Passive 400 W; Bi-amp LF 400 W, HF 50 W
Power Rating (PGM): Passive 800 W; Bi-amp LF 800 W, HF 100 W
Power Rating (PEAK): Passive 1600 W; Bi-amp LF 1600 W, HF 200 W
Nominal Impedance: Passive 8 Ω; Bi-amp LF 8 Ω, HF 16 Ω
SPL Sensitivity (1 W, 1 m, on axis): Passive 97 dB; Bi-amp LF 99 dB, HF 108 dB
Peak SPL (Calculated): Passive 129 dB; Bi-amp LF 131 dB, HF 131 dB
I/O Connectors: SpeakON NL4MP ×2 (Parallel)
Handle: Aluminium Die-cast, Side ×2
Pole Socket: Ø35 mm ×2 (0° or −7°)
Rigging: M10 ×12
Options: Bracket UB-DZR15H/V; Cover SPCVR-DZR15
Product Weight: 21.3 kg / 47.0 lbs.
Product Dimensions (L × W × H): 18.1" × 17.7" × 30.0"
